Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck
Maximize your mining efficiency with the HOWO 8x4 On-Site Mixed ANFO Explosive Truck – a 15-ton intelligent blasting vehicle featuring a 400HP WEICHAI engine, 15-18m³ stainless steel multi-compartment material box, integrated diesel tank, PLC digital control with ±2% dosing accuracy, three-stage spiral conveying system, and handheld remote control. Built on the robust HOWO 8x4 chassis with 8-speed manual transmission, this vehicle enables precise, safe, and efficient on-site explosive mixing and loading for open-pit mining operations.
Sinotruk HOWO 8x4 ANFO Explosive Mixing Truck
The HOWO On-Site Mixed ANFO Explosive Truck is a specialized mining vehicle that integrates the transportation, mixing, and loading of raw materials directly at the blast hole . Built on the proven HOWO 8×4 heavy-duty chassis with a 1,800+3,775+1,400mm wheelbase and HOWO cab (LHD/RHD with A/C), this vehicle features a WEICHAI WP12.400E201 diesel engine delivering 400HP (257kW) with Euro III compliance, paired with an HW19710 10-speed manual transmission and HW70 flange PTO . The core system comprises a 15-18m³ stainless steel dry material box divided into multiple compartments for porous ammonium nitrate, a 1.0-1.2m³ diesel tank, and a three-stage spiral conveying system that enables precise delivery of materials to the blast hole . The advanced PLC computer digital control system allows operators to set precise ingredient ratios, with dosing accuracy maintained within ±2% . The vehicle is equipped with safety systems including over-temperature and over-pressure alarms, automatic shutdown on material shortage, and handheld remote control for safe distance operation . GPS/BeiDou positioning enables real-time vehicle tracking .
Key Features:
· Sinotruk HOWO 8×4 Heavy-Duty Chassis: Robust 8×4 configuration for excellent stability on mining sites. HOWO cab with LHD/RHD, A/C. GVW 31,000-32,000kg. 12R22.5 tires (12 + 1 spare). Front axle 6.5-7.0T, rear axles 18.5T tandem .
· WEICHAI 400HP Euro III Engine: WP12.400E201, 400HP (257kW). HW19710 10-speed manual transmission (10F+2R). HW70 flange PTO. Speed limited to 80 km/h for safety .
· 15-18m³ Stainless Steel Multi-Compartment Dry Material Box: 15-18m³ total volume (14.5-16.8m³ effective). SS304 stainless steel, 4mm thickness. Multi-compartment design for separate transport of ammonium nitrate. Funnel/droplet shape with stiffeners for material flow .
· Integrated Diesel Fuel Tank: 1.0-1.2m³ capacity (approx. 1,000-1,100kg diesel). For on-site mixing with ammonium nitrate to produce ANFO explosive .
· Three-Stage Spiral Conveying System: Quantitative spiral, vertical spiral, and top spiral for precise material delivery. 350° rotation with 5m operating radius .
· PLC Digital Control System: Precise ingredient ratio control. Dosing accuracy ≤±2% . Real-time monitoring of material flow. User-friendly interface for operators.
· Safety & Alarm Systems: Over-temperature and over-pressure automatic alarms . Material shortage alarm with automatic shutdown . Handheld remote control for safe distance operation. GPS/BeiDou positioning system .
· Safety Equipment: EBS/ABS control system . Front wheel disc brakes. Engine exhaust brake and air-operated parking brake. Forward-positioned exhaust pipe. Front wheel tire burst emergency protection device. Speed limiter (80 km/h) .
Application:
· Open-Pit Mining: Primary blasting for ore extraction in copper, gold, iron ore, coal, and other mineral mining operations.
· Quarry Operations: Rock fragmentation for aggregate and dimension stone production.
· Large-Scale Infrastructure: Blasting for road construction, tunnel excavation, and dam foundation work.
· Mining Contractor Services: Contract blasting services for multiple mining operations.
· Explosive Logistics: On-site mixing eliminates the need for pre-packaged explosives, reducing logistics costs and safety risks.
Product Specification
| Chassis | Sinotruk HOWO 8×4 (LHD/RHD) |
| Overall Dimensions | 9,850-11,600 × 2,500-2,550 × 3,900-3,980 mm |
| Wheelbase | 1,800 + 3,775 + 1,400 mm |
| GVW / Payload | 31,000-32,000 kg / 15,000-16,500 kg |
| Engine | WEICHAI WP12.400E201, 400 HP (257 kW), Euro III |
| Transmission | HW19710, 10F+2R |
| Max Speed | 80 km/h |
| Tires | 12R22.5 / 295/80R22.5 (12+1) |
| Dry Material Box | 15-18 m³ (14.5-16.8 m³ effective), SS304, 4mm |
| Dry Material Capacity | 15-16.5 tons |
| Diesel Tank | 1.0-1.2 m³ (approx. 1,000-1,100kg) |
| Dosing Accuracy | ≤±2% |
| Charging Arm | 350° rotation, 5m radius |
| Control System | PLC digital with handheld remote |
| Positioning | GPS + BeiDou |
| Safety | EBS/ABS, speed limiter, disc brakes, forward exhaust, alarm shutdown |
| Applications | Mining, quarrying, infrastructure blasting |
