Sinotruk HOWO 6x6 High-Mobility Tactical Troop Carrier Truck
The FAW J6L 5,000L/2,000L Fire Fighting Truck represents the pinnacle of medium-duty fire apparatus engineering. Designed for municipal departments and industrial brigades, this unit combines a reliable FAW J6L chassis with a high-capacity 5,000-liter water tank and a dedicated 2,000-liter foam system. It delivers superior extinguishing power for both Class A (combustibles) and Class B (flammable liquids) fires, ensuring operational readiness for complex emergency scenarios.
Sinotruk HOWO 6x6 High-Mobility Tactical Troop Carrier Truck
Engineered to meet the rigorous demands of modern defense forces, the HOWO 6×6 Troop Carrier bridges the gap between heavy commercial trucking and tactical military mobility. Manufactured in China’s original OEM facilities, this vehicle prioritizes mechanical redundancy, payload integrity, and crew survivability. It serves as the backbone for troop transport, peacekeeping logistics, and disaster response operations requiring heavy-duty off-road capability.
Key Features:
1. Tactical Mobility (6×6 Configuration):
The permanent 6×6 all-wheel-drive system with heavy-duty inter-axle differentials provides exceptional traction in soft sand, deep mud, and snow. The high ground clearance and approach/departure angles are optimized to clear vertical obstacles and ford deep water crossings.
2. Proven Powertrain:
· Engine: SINOTRUK WD615.47 (Euro II / III compliant options), 9.726L inline-6. Delivers 371HP @ 2,200 rpm and 1,500 N.m peak torque for sustained climbing power under full load.
· Transmission: Robust HW19710 10-speed manual gearbox (10F/2R) with low gearing for precise crawl-speed control during technical off-road maneuvers.
3. Structural Integrity & Load Capacity:
· Chassis: Reinforced ladder frame with high-strength steel cross-members.
· Axles: Rated at 7,000 kg (Front) and 16,000 kg x2 (Rear), featuring hub reduction for increased ground clearance and torque multiplication at the wheels.
· Payload: Designed to carry a combat-loaded squad with full kit and supplies.
4. Combat-Ready Survivability Features:
· Braking Safety: Dual-circuit air brakes with ABS integration. Includes an engine exhaust brake for safe descent control on mountain gradients, reducing brake fade.
· Operational Range: Equipped with a 400-liter fuel capacity, allowing for extended patrol range without logistical resupply.
· Hardware: Lockable fuel and fluid caps, blackout lighting provisions, and heavy-duty towing pintles front and rear.
5. Crew Compartment & Cargo Area:
· Cabin: HW76 “Long” cab with single sleeper, air conditioning, and advanced ventilation. Can be fitted with ballistic or mine-protection lining upon request.
· Troop Carrier Body: Steel floor (3mm Q235) with reinforced side rails. Fitted with 3 rows of longitudinal steel bench seats equipped with integrated safety belts to secure personnel during high-impact maneuvers.
Applications:
· Military Troop Transport: Primary personnel movement for infantry units.
· UN Peacekeeping Missions: Reliable logistics in areas with damaged infrastructure or mine threat.
· Border Patrol & Internal Security: Sustained patrols in remote border regions.
· Humanitarian Aid & Disaster Relief: First-response supply delivery to earthquake or flood-isolated areas.
· Command & Communications Variant: Ready-to-modify platform for housing tactical communication systems.
Product Specification
| Truck Chassis | |||
| Condition | New condition/left hand drive/6X6 | ||
| Chassis | Brand | Sinotruk Howo | |
| Curb weight(kg) | 14300 kg | ||
| Wheelbase(mm) | 4600+1400 mm | ||
| Dimensions(mm) | 10500X2500X3450 mm | ||
| Front/Rear Axle loading(kg) | 7000kg | ||
| 16000kgX2 | |||
| Max. driving speed(km/h) | 95 | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels | ||
| Auxiliary brake: engine exhaust valve brake | |||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10 pcs with one spare tire | |
| Specifications | 12.00R20 | ||
| Fuel box | 400L with lockable cap | ||
| Transmission | Manual type HW19710, 10 Forwards and 2 reverse | ||
| Cab | HW76 cabin with single sleeper | ||
| White color | |||
| With Air Conditioner | |||
| With front protection device | |||
| Engine | Brand | SINOTRUK | |
| Model | WD615.47 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 9726 ml | ||
| Power(kw) | 273kw | ||
| Horsepower(HP) | 371HP | ||
| Max. Torque(N.m) | 1500 | ||
| Fuel consumption at full load(g/kw.h) | 193 | ||
| Cylinder number | In-line 6 cylinders,water cooling,four-stroke,super-charge and middle cooling,direct-injection | ||
| Emission standard | Euro II | ||
