ISUZU KV600 Mobile Clinic Truck

The ISUZU KV600 Mobile Medical Clinic Truck is a specialized vehicle designed to function as a mobile clinic or mobile checkup vehicle, eliminating the need for a fixed hospital. Built on the reliable, fuel-efficient ISUZU KV600 light-truck chassis, it is ideal for long rural trips and suburban mobile clinics. The independent, sealed medical pod is isolated from the cab and built with medical-grade panels that are mold-resistant, antibacterial, and easy to disinfect and clean. The exterior graphics list a comprehensive range of services: annual checkups, X-ray & lab tests, ECG, drug testing, vaccinations, family planning, and mental health. Inside, the pod is intelligently laid out with two main workstations. The left side features a long counter for records and sample registration, overhead cabinets for supplies, and a service window for outdoor sample intake, with a roof-mounted AC maintaining a constant temperature ideal for reagents. The right side features a computer desk for entering patient records, a flat exam bed in the center, a medical office chair, and storage cabinets for medicines and instruments. The floor is covered with non-slip medical PVC flooring that is waterproof, scrub-resistant, and easy to disinfect, while the ceiling features recessed lighting for even, soft illumination. Custom-built for overseas medical institutions, the pod allows for X-ray machines and lab equipment to be added later, with reserved equipment mounting points and power/data wiring for high flexibility.

Key Features:

1. Reliable ISUZU KV600 Chassis – Built for Rural & Suburban Trips: The 4×2 chassis features a 3,360mm wheelbase and a 7,000kg GVW. It comes with an original ISUZU KV600 single-row cabin equipped with air conditioning, power assistance, central lock, electric windows, and a rear camera. The front and rear axle loading is 3,000/5,500 kg.

2. Efficient 132HP Euro 6 Engine: Powered by a 4KH1CN6HB diesel engine (2,999ml, 4-cylinder, water-cooled, turbocharged, after-cooled), paired with a 6-speed manual transmission and a reinforced diaphragm clutch. The vehicle achieves a max speed of 95 km/h, making it ideal for long-distance outreach.

3. Medical-Grade Sealed Pod – Built for the Philippines Climate: The 4,200×2,100×2,100mm (18.1m³) pod features an outer FRP fiberglass layer, PU foam insulation core, and inner medical-grade FRP clean panels. A lead sheet is built into the inner wall of the DR room to block X-ray leakage. FRP advantages include being waterproof, wipe-clean, and mold-resistant, making it perfect for the hot, humid Philippines. The smooth, non-porous surface resists bacteria. The gray PVC medical anti-slip flooring is disinfectant-resistant.

4. Dual Workstations for Efficient Patient Flow:

· Left Station: Long counter for records and sample registration, overhead cabinets for supplies, and a service window for outdoor sample intake.

· Right Station: Computer desk for entering patient records and checkup data, a flat exam bed in the center, a medical office chair, and storage cabinets for medicines and instruments.

5. Comprehensive Interior Medical Devices: The vehicle comes equipped with a six-gang light switch panel, DR X-ray tube and high-voltage generator housing, roof overhead cabinets with emergency light and smoke alarm, an integrated vehicle power distribution control cabinet, a consultation & registration booth, a wall-mounted AC indoor unit, an exterior pod door, a DR flat panel detector (motorized lift column + foot switch), and a DR imaging workstation desk.

6. Privacy & Comfort: Blue medical divider curtains create separate exam areas inside, ensuring privacy for consultations and checkups. The roof-mounted AC maintains a constant temperature, which is ideal for reagents.

7. Highly Flexible for Retrofitting: Custom-built for overseas medical institutions. The pod reserves equipment mounting points and power/data wiring, so medical devices like X-ray machines and lab equipment can be added or removed later.

Application:

· Mobile Health Outreach: Travels to villages and remote communities for on-site annual checkups, vaccinations, and basic screening.

· Corporate & Factory Clinics: Provides on-site health checks and drug testing for employees at factories and industrial parks.

· Public Health Campaigns: Supports government and NGO initiatives for family planning, mental wellness, and disease prevention.

· Diagnostic Imaging: The lead-lined DR room enables safe, on-site X-ray imaging for community screening.

· Emergency Relief: Acts as a rapid-response medical unit for disaster-stricken areas.
