ISUZU KV600 9m³ Compacotor Garbage Truck
Engineered for the unique challenges of Southeast Asian waste management, the Isuzu KV600 9-cubic meter compression garbage truck delivers a powerful combination of durability, maneuverability, and high efficiency. Designed to perform in high-temperature environments and navigate congested urban roads, this unit is the ideal solution for municipalities and private collectors seeking to reduce operational costs while maximizing load capacity.
ISUZU KV600 9m³ Compacotor Garbage Truck
The Isuzu KV600 is more than just a truck; it is a comprehensive waste management solution built to withstand the rigors of daily use in tropical climates. Featuring a robust 132 HP diesel engine and a strategically optimized 3815mm wheelbase, this model provides the perfect balance between power for heavy loads and agility for tight city streets. Whether operating in the bustling centers of Manila or the developing suburbs of Hanoi, the KV600 ensures reliable, high-productivity performance.
Key Features
1. Proven Powertrain for Tropical Conditions:
At the heart of the KV600 is a reliable 132 HP diesel engine. Calibrated for high-ambient temperatures, it guarantees consistent power delivery on challenging routes, significantly reducing the risk of downtime and lowering long-term maintenance costs.
2. Urban-Friendly Maneuverability:
With a compact design centered around a 3815mm wheelbase, this garbage compactor is purpose-built for navigating narrow alleyways and high-density traffic. It offers exceptional maneuverability, allowing operators to access collection points that larger trucks cannot reach.
3. High-Efficiency Compression Technology:
The 9-cubic meter body utilizes advanced compaction mechanisms to maximize waste density. This allows for fewer trips to the landfill, directly translating to significant savings on fuel consumption, labor hours, and overall fleet operational expenses.
4. Climate-Adapted Durability:
Built to endure Southeast Asia’s humidity and coastal conditions, the KV600 features enhanced cooling systems for the engine and transmission, alongside corrosion-resistant materials in the body and chassis to protect against rain and saline air.
5. Operator-Centric Cabin Design:
Driver fatigue is minimized thanks to a thoughtfully designed cabin that prioritizes ergonomics, superior visibility, and intuitive controls. Safety features are integrated throughout to ensure secure operation during long shifts in busy environments.
Applications
Municipal Urban Sanitation: Ideal for daily household waste collection in cities and large towns.
Private Waste Collection: A cost-effective asset for private companies servicing residential estates and commercial districts.
Industrial & Commercial Use: Suitable for collecting non-hazardous waste from factories, hotels, and large market complexes.
Product Specification
| ISUZU 9m³ Compressed Garbage Truck | ||
| Chassis Model | QL111 | |
| Driving Model | 4X2 | |
| Cab | Original ISUZU KV600 cabin | |
| Left Hand Driving | ||
| With air conditioner | ||
| Central lock | ||
| Steer Assistance | ||
| Electric Window | ||
| Wheel Base | 3815 mm | |
| Axle Loading (front/rear) | 3000 / 5500 kg | |
| External Dimensions (L x W x H) | 9000x2550x3280mm | |
| Net weight (Kg) | 5060 | |
| Approach / Departure angle | 20/12° | |
| Max. driving speed | 105 km/h | |
| Engine | Model | 4KH1CN6LB |
| Type | ISUZU diesel engine, | |
| 4 cylinders in a line, | ||
| Water cooled,turbocharged,after cooled , cold start. | ||
| Horse Power | 132Hp | |
| Emission standard | Euro 2 | |
| Displacement | 2999 ml | |
| Gearbox | Manual type | |
| 6 forwards & 1 reverses | ||
| Clutch | Reinforced diaphragm clutch | |
| Tire | 7.00R16 | |
| 6 Pcs with 1 spare tire | ||
| Fuel box | 120L /steel material | |
| Garbage Truck Body | ||
| Tanker body material | Quality high tensile Q345 carbon steel | |
| Shape | rectangular box, arc-shaped rear | |
| Thickness | Side 5mm, Bottom 6mm | |
| Garbage Container Size | 9 CBM | |
| Filling hopper volume | 0.8 CBM | |
| Sewage box of filling hopper | 180L | |
| Working rotation speed | 1300 r/min | |
| Idle Speed | 750 rpm | |
| Compaction ratio | 0.7-0.85T/m³ | |
| Compacting cycle time | ≤28 s | |
| Loading cycle time | ≤10 s | |
| Unloading cycle time | ≤48 s | |
| Oil pump displacement | 50 ml/r | |
| Hydraulic oil box size | 80 L | |
| System pressure | 16 Mpa | |
| PTO operation method | Pneumatic | |
| Operation and Control | Both Automatic(Electrical) and Manual (hydraulic) | |
| Others | With Pneumatic cover to avoid waste flying away during driving | |
| Optional parts | Garbage Compactor whole body will be Electrophoresis treated for long time painting | |
| With remote control function | ||
ISUZU KV600 9m³ Compacotor Garbage Truck
- +86 199 4767 5585
- [email protected]
- Industry Park, Suizhou City,Hubei Province, China
Company Profile
Aout TWL
HUBEI TWL SPECIAL VEHICLE CO., LTD (hereinafter referred to as TWL), one of important member of CLW Group, is located in Suizhou City, Hubei Province, the capital of China’s Special Vehicles. TWL Truck has a first-class management, design, R&D, manufacturing, and sales professional team, as well as “special, new, high and sophisticated” facilities and equipment, complete manufacturing technology, and strict testing methods to ensure the production of high-quality and high-value-added products for the market. At present, we has strategic partnership with a number of well-known Chinese truck brand, including Dongfeng, Sinotruk, FAW, Foton, Shacman, ISUZU, JAC, JMC, Kama, etc. TWL Truck always adheres to the corporate philosophy of “people-oriented, customer-oriented, honesty and win-win”, and adheres to the business tenet of “development by innovation, survival by quality; integrity by service, and market by brand”.
After-Sales Service
Warranty
– The buyers can get a minimum warranty period of 12 months or 25000KM-50000KM, whichever comes first from the arrival date of shipment.
– During this period, we will send replacement parts and components to buyers by DHL, UPS, FEDEX or by air and by sea free of charge, easy-wearing spare parts are excluded.
– After warranty time, buyers can get all of spare parts of their truck at factory cost.
– This warranty does not cover any possible damage due to improper operaton, accident or misuse or damage due to any unauthorized services.
Technical Support
– The buyers can forever enioy technical support anytime and anywhere, overseas technical training before operaton is available at buyers cost or our cost.
Daily Mainteance Suggestion
– We strongly sugest you to buy some amount of basic spare pats along with your truck, the cost will be approximately 500 USD-800 USD/unit, no shipping cost.
