ISUZU KV100 RHD 20,000-Chick Transport Truck
The ISUZU KV100 Chick Transport Truck is a professional-grade livestock vehicle specifically designed for the safe, humane transport of day-old chicks in right-hand drive African markets. Built on the proven ISUZU KV100 4×2 chassis with 3,360mm wheelbase and KV100 single-row cab (RHD with A/C), this vehicle features an ISUZU 4KH1CN6LB diesel engine delivering 120HP with Euro IV compliance, paired with an MSB 5-speed manual transmission. The 4.2m cargo box (4,200×2,400×2,400mm) is constructed with FRP inner/outer panels and high-density polyurethane insulation, featuring densely arranged circulating ventilation louvers on both sides for layered airflow to prevent chick suffocation. Internal partition shelves create multi-tier racks for chick transport baskets, enabling a load capacity of up to 20,000 chicks. The Carrier refrigeration unit provides precise temperature control at 26-30°C – the optimal transport temperature for chicks – shielding them from Malawi’s daytime heat. The suspension is tuned for heavy-load comfort on potholed and gravel roads common in Africa. The ISUZU chassis is highly reliable, resistant to high temperatures and dust, and well-suited to Malawi’s tropical hot climate.
Key Features:
1. ISUZU KV100 4×2 RHD Chassis – Reliable & Adaptable: Powered by the ISUZU 4KB1 diesel engine, rated at 120 HP. Features low fuel consumption and minimal failure rate. Maintenance parts widely available in Malawi and convenient servicing even in remote townships. Torque output smooth for unpaved rural roads.
2. 4.2m Chick Specialized Box – Core Ventilation Design: Distinct from ordinary fresh-keeping refrigerated boxes, this is custom-designed for day-old chick transport. Features densely arranged circulating ventilation louvers on both sides, enabling layered airflow from top to bottom to prevent chick suffocation. Internal partition shelves create multi-tier racks for chick transport baskets.
3. Carrier Refrigeration Unit – Precise Temperature Control: World-leading cold-chain refrigeration brand. Optimal chick transport temperature is 26-30°C (chicks cannot tolerate freezing and require constant warmth, humidity, and ventilation). Unit reliably maintains this constant temperature, shielding chicks from Malawi’s high-temperature exposure. Heat-resistant and dust-resistant for tropical environments.
4. 20,000-Chick Payload Capacity: Single-vehicle load capacity offers optimal efficiency for small-to-medium batch deliveries – perfectly aligned with Malawi’s local farming scale. Internal shelves create multi-tier racks for chick transport baskets, maximizing space utilization.
5. Durable Construction for African Road Conditions: Suspension tuned for heavy-load comfort, effectively cushioning bumps on potholed and gravel roads. ISUZU chassis highly reliable, resistant to high temperatures and dust. Braking stable for short suburban hauls and narrow rural roads.
6. Hygienic Design: Smooth inner walls easy to wash and disinfect, meeting veterinary epidemic prevention requirements for livestock transport. Facilitates return-trip cleaning and sanitization.
7. Optional Humidity Adjustment: Prevents overly dry conditions inside the box that could cause chick dehydration and death – essential for live poultry transport.
8. Lightweight Design: Lightweight, waterproof, moisture-proof, capable of withstanding Malawi’s intense sunlight and humid rainy seasons.
Application:
· Day-Old Chick Transport to Malawi: Primary application: transporting day-old chicks from large-scale hatcheries to township farms and smallholder free-range bases across Malawi.
· Transport Routes: After port customs clearance, handles short suburban deliveries plus long-distance rural transfers, covering both paved highways and rural gravel/dirt roads.
· Payload Matching: Single-vehicle load capacity of 20,000 chicks offers optimal efficiency for small-to-medium batch deliveries – neither too large nor too small.
· Poultry Logistics: Safe, temperature-controlled transport for day-old chicks, ducklings, and other young poultry.
· Agricultural Logistics: Reliable transport for poultry farms, hatcheries, and livestock distributors.
Product Specification
| ISUZU KV100 4×2 Reefer Truck | |
| Chassis Specification | |
| Chassis Model | QL104 |
| Driving Model | 4×2 |
| Dimension | 6500×2500×3000 mm |
| Cab | · Original ISUZU kv100 single row cabin |
| · Right Hand Driving | |
| · With Air Conditioner | |
| Wheelbase | 3360 mm |
| Gross vehicle Weight | 4495 kg |
| Curb Weight | 2295 kg |
| Front Axle Loading Capacity | 2500 kg |
| Rear Axle Loading Capacity | 4800 kg |
| Axle Number | 2 |
| Engine | ISUZU diesel engine |
| 4 cylinders in a line, | |
| Water cooled, turbocharged, after cooled, cold start. | |
| Model:4KH1CN6LB | |
| Horse power: 120HP | |
| Displacement: 2999ml | |
| Emission standard: Euro 4 | |
| Transmission | ISUZU, MSB |
| 5 Forward & 1 Reverse | |
| Tire | 7.00R16 |
| 6pcs with 1 spare tire | |
| Upper Body Specifications | |
| Van Size | 4200x2400x2400 mm |
| Max. Loading Capacity | 20,000 |
