ISUZU GIGA 6x4 15-Ton Flatbed Wrecker Truck
Engineered for heavy-duty vehicle recovery and equipment transport, the ISUZU GIGA 6x4 Wrecker Truck is a 15-ton flatbed recovery vehicle built on the reliable ISUZU GIGA 6x4 chassis. Featuring a 460HP ISUZU 6WG1-TCG61 Euro VI engine, FAST 12-speed manual transmission (12F+2R), 8,000×2,500mm flatbed platform (6mm checker plate, 16mm manganese frame), 15-ton hydraulic winch, 10-ton rear lifting arm, 10-ton XCMG folding boom crane (4,000kg @ 2.5m, 12.4m radius, 15.4m height), and aluminum alloy box plate, this vehicle delivers exceptional recovery capability for trucks, buses, construction equipment, and heavy commercial vehicles.
ISUZU GIGA 6x4 15-Ton Flatbed Wrecker Truck
The ISUZU GIGA 6×4 Wrecker Truck is a professional-grade heavy-duty recovery vehicle designed for towing companies, highway maintenance departments, municipal fleets, and industrial facilities requiring reliable, efficient recovery of heavy vehicles. Built on the proven ISUZU GIGA 6×4 chassis with a 5,200+1,370mm wheelbase and VC66 cab (LHD with sleeper, A/C, pneumatic seat, electric doors/windows), this vehicle features an ISUZU 6WG1-TCG61 diesel engine delivering 460HP (15,681ml, Euro VI) with a FAST 12-speed manual transmission (12 forward + 2 reverse). The 8,000×2,500mm flatbed platform is constructed with 6mm checker plate and 16mm thick manganese frame, offering 20-ton loading capacity. The 15-ton hydraulic winch provides powerful pulling capacity. The 10-ton rear lifting arm enables secondary vehicle recovery. The XCMG 10-ton folding boom crane (4,000kg effective @ 2.5m, 12.4m working radius, 15.4m lifting height) with 360° rotation and H-shape outriggers provides versatile lifting capability. The hydraulic back platform (2,400×2,500mm) facilitates efficient loading/unloading.
Key Features:
· ISUZU GIGA 6×4 Heavy-Duty Chassis: 5,200+1,370mm wheelbase for superior stability. VC66 cab with sleeper, LHD, A/C, pneumatic seat, electric doors/windows. Front axle 9,000kg, rear axles 13,000kg×2. GVW 35,000kg. 385/65R22.5 front / 315/80R22.5 rear tires (10 + 1 spare). 400L fuel tank. Air brakes with ABS.
· ISUZU 460HP Euro VI Engine: 6WG1-TCG61, 460HP, 15,681ml displacement. 6-cylinder inline, water-cooled, turbocharged, after-cooled. Euro VI emission compliance. Strong torque for heavy recovery operations.
· FAST 12-Speed Manual Transmission: 12 forward + 2 reverse gears. Smooth power delivery for heavy loads.
· 8,000×2,500mm Heavy-Duty Flatbed: 6mm checker plate construction. 16mm thick manganese frame. 20-ton loading capacity. Telescoping mechanism for flexible loading.
· 15-Ton Hydraulic Winch: Powerful pulling capacity for disabled vehicle recovery. Effortless towing and load stabilization. Ensures safe and stable transport.
· 10-Ton Rear Lifting Arm: Enables secondary vehicle recovery. Versatile towing capability.
· XCMG 10-Ton Folding Boom Crane: 4,000kg effective lifting capacity at 2.5m. 12.4m maximum working radius. 15.4m maximum lifting height. 360° rotation. H-shape legs with 2 hydraulic outriggers with lifting function.
· Aluminum Alloy Box Plate: Lightweight, corrosion-resistant construction. Durable for long-term use.
· Hydraulic Back Platform: 2,400×2,500mm platform for efficient loading/unloading. Acts as ramp for safe winching of disabled vehicles.
· Premium Components: Isuzu chassis with ABS, pneumatic seat, and electric windows for operator comfort and safety.
Application:
· Heavy Truck & Commercial Vehicle Recovery: Recovery of disabled semi-trucks, box trucks, and commercial vehicles. The 15-ton capacity handles the heaviest loads.
· Bus & Coach Towing: Professional recovery of buses, coaches, and passenger transport vehicles.
· Construction Equipment Transport: Moving construction equipment including excavators, loaders, and bulldozers. The telescoping flatbed accommodates oversized machinery.
· Municipal Fleet Vehicle Recovery: Recovery of municipal vehicles including garbage trucks and utility vehicles.
· Highway Accident Scene Clearance: Rapid clearance of accident scenes involving heavy vehicles. The 15-ton winch and 10-ton crane provide comprehensive recovery capability.
· Industrial Equipment Relocation: Moving heavy industrial equipment within facilities and between locations.
Product Specification
| Chassis Specification | |
| Chassis Model | QL5350 |
| Driving Model | 6X4 |
| Cab | ISUZU GIGA VC66 Cabin, with one sleeper |
| Left Hand Drive | |
| With Air Conditioner | |
| With Pneumatic Seat | |
| Electric doors and Windows | |
| Dimension | 11500 x 2500 x 3900 mm |
| Wheelbase | 5200+1370 mm |
| Gross vehicle Weight | 35000 kg |
| Front Axle Loading Capacity | 9000 kg |
| Rear Axle Loading Capacity | 13000 kg x2 |
| Axle Number | 3 |
| Engine | ISUZU diesel engine |
| 6 cylinders in a line, | |
| Water cooled, turbocharged, after cooled, cold start. | |
| Model: 6WG1-TCG61 | |
| Horse power: 460 HP | |
| Displacement: 15681 ml | |
| Emission standard: Euro 6 | |
| Transmission | Model: FAST Manual Type |
| 12 Forward & 2 Reverse | |
| Tire | Front: 385/65R22.5 |
| Rear: 315/80R22.5 | |
| 10 Pcs with one spare tire | |
| Fuel Tank Capacity | 400L |
| Brakes | Air brake, With ABS |
| Upper Body Specifications | |
| Flatbed Platform | Size: 8000 x 2500 mm |
| Thickness : 6mm checked plate | |
| Loading Capacity: 20 Ton | |
| Frame: 16 mm Thick manganese plate | |
| Winch | 15 Ton |
| Rear Lifting Arm | 10 Ton |
| Box Plate | Material: Aluminum Alloy |
| Hydraulic Back Platform | 2400 x 2500 mm |
| 10Ton Folding Boom Crane Specifications | |
| Working Platform | 360°turning (left or right), H-shape legs 360° |
| Max. Lifting Capacity | Effectively: 4000 kg at 2.5 meters |
| Max. Working Radius | 12.4 meters |
| Max. Lifting Height | 15.4 meters |
| Outrigger | 2 Pcs hydraulic outrigger |
| With lifting function | |
