ISUZU FVR Flatbed Tow Truck
The strength of this vehicle lies in its ability to deliver near-heavy-duty recovery truck performance and compliance, all while maintaining the agility and cost-effectiveness of a medium-duty truck, thanks to its two core features: the three-section full-ground-contact deck and the liftable axle. This results in exceptionally high value for money and broad applicability.
ISUZU FVR Flatbed Tow Truck
Key Feature
1.Advantages of Wheelbase and Maneuverability (5800mm Wheelbase)
Excellent Road Adaptability: A 5800mm wheelbase is considered the “golden size” for recovery trucks. It ensures stable highway performance while offering a better turning radius and maneuverability compared to long-wheelbase heavy-duty trucks. This makes it suitable for flexible operations in various scenarios such as urban roads and highways.
Rational Superstructure Layout: This wheelbase provides an ideal platform for installing the three-section deck, ensuring sufficient deck length while maintaining balanced load distribution between the front and rear axles.
2.Core Performance Advantages (300 HP + Liftable Axle)
Powerful and Economical: Isuzu’s 300 HP engine is renowned for its reliability, low fuel consumption, and minimal maintenance costs. For a model with a gross weight of around 25 tons, this power output is sufficient to handle the majority of recovery tasks while offering far better fuel efficiency than larger-displacement heavy-duty engines, reducing operational costs.
3.Strategic Value of the Liftable Axle:
Maximized Weight Reduction and Increased Payload: When not in operation, running empty, or under light loads, the liftable axle can be raised. This not only reduces tire wear and fuel consumption but, more importantly, converts the weight of the axle (typically over 1 ton) into additional legal payload capacity. This is critical for markets with weight-based tolling and strict overload regulations.
Perfect Compliance with Axle Load Regulations: In countries with stringent axle load restrictions (e.g., Europe, Australia, the Middle East, South America), the liftable axle acts as a “compliance tool.” During operation, lowering the liftable axle increases the number of load-bearing axles, significantly reducing the load on each axle, making it easy to meet local axle load limits and avoid hefty fines.
Enhanced Stability During Operations: When recovering or towing vehicles, lowering the liftable axle increases the vehicle’s ground contact area and overall stability, improving driving safety.
4.Superstructure Functional Advantages (Three-Section Full-Ground-Contact Deck)
Powerful Operational Capability and Convenience:
Full-Ground-Contact Design: The deck can be fully lowered to ground level, significantly reducing the approach angle and difficulty of loading vehicles (especially those with low ground clearance or unable to move due to damage). This enables safer and easier loading, offering a major advantage over “tilt decks” or “two-section decks.”
Length of the Three-Section Deck: Typically providing a longer loading platform (approximately 7–9 meters), it can not only tow standard passenger cars and light commercial vehicles but also safely and securely handle long-wheelbase trucks, buses, and even medium-sized coaches, expanding the range of services.
Versatility: The full-ground-contact three-section deck is ideal for “all-wheels-down” towing and flatbed transportation, making it the most mainstream and efficient method for handling accident-damaged or broken-down vehicles.
Application:
1.Urban and Intercity Road Rescue
A 5800mm wheelbase allows easy navigation through narrow streets, while the liftable axle ensures compliance with heavy-load regulations, making it suitable for towing accident vehicles in cities and stranded vehicles on highways.
2.Logistics Park/Port Internal Recovery
The fully grounded three-section deck enables quick handling of sudden breakdowns of container trucks, freight trucks, and other commercial vehicles, ensuring logistics efficiency.
3.Car Rental Companies/Fleet Management
Efficiently relocating faulty rental vehicles or company fleet vehicles, the 300 HP engine provides sufficient power to handle medium-sized buses and trucks.
4.Law Enforcement Vehicle Impoundment
Used by police or municipal departments for impounding non-compliant vehicles, the fully grounded deck design allows safe towing of various low-clearance modified or stolen vehicles.
5.Airport/Transport Hub Emergency Response
Towing faulty shuttle buses or cargo vehicles around airport aprons or passenger hubs without disrupting the operations of transportation hubs.
Product Specification
| Mixing Drum | |
| Drum Full Capacity | 12 CBM |
| Drum Size | Diameter: ⌀2300mm Length: 4730mm |
| Material | Q345 High quality wear-resistance steel |
| Thickness | Drum body is 5mm, shell head is:6mm |
| Feeding Speed (m³/min) | ≥2.8 m³/min |
| Discharging Speed (m³/min) | ≥2 m³/min |
| Discharging Residual(%) | ≤0.5 % |
| Mixing Tank Rotating Speed (r/min) | 0-17 r/min |
| Discharging Chute | Add an 40cm extended auxiliary chute , and rotate 180°in the horizontal direction |
| Color & Logo | Customized according to customer requirements |
| Driving system | |
| Hydraulic Pump | Interpump, Italian Brand |
| Hydraulic Motor | Interpump, Italian Brand |
| Reducer | PMP Reducer, Italian Brand |
| Radiator | KLMAKE 18L, China local brand |
| Water supply system | |
| Water Tank Capacity (liters) | 400L |
| Water supply type | Pneumatic water supply |
| Key Features & Advantages | 1.Fast feeding: Streamlined hopper body, conical expansion technology, new structure for fast loading |
| 2.Two washing nozzles (one at ground level by quick joint and one on ladder platform) | |
| 3.Two manholes on the drum and two safety drum locking systems | |
| 4.The three-stage blades can provide an efficient discharge angle | |
| 5.Lightweight and high loading capacity: Without a sub-frame structure, reduci | |
