ISUZU 100P 5m³ Diesel Refueling Truck
The TWL Isuzu 100P 5m³ Diesel Refueling Truck offers a safe, efficient, and versatile solution for mobile fuel delivery. Built on a robust Isuzu 100P chassis and powered by the 4KH1CN6LB engine, it ensures dependable performance, right-hand drive adaptability, and high safety standards for on-site refueling and diesel transportation.
ISUZU 100P 5m³ Diesel Refueling Truck
The TWL Isuzu 100P 5-cubic meter diesel refueling truck is a purpose-built vehicle engineered for safe and efficient mobile fuel supply. Designed on Isuzu’s reliable 100P commercial chassis and configured with right-hand drive, it meets the diverse requirements of global markets such as Southeast Asia, Africa, and Oceania.
Powered by the Isuzu 4KH1CN6LB 120HP diesel engine, this refueling truck delivers strong power with low fuel consumption while meeting China VI emission standards. The ABS braking system, durable 7.00R16 tires, and optimized axle configuration ensure exceptional stability, safety, and performance under varied road and climate conditions.
The 5m³ fuel tank features internal anti-surge baffles to prevent liquid impact during transport, along with anti-corrosion materials and safety equipment including a grounding strap and fire extinguisher. Optional components—such as electric pumps, fuel meters, hose reels, and automatic shut-off systems—offer flexible customization to meet specific operational needs.
This refueling truck is ideal for construction sites, mining operations, agricultural projects, transportation fleets, remote communities, and emergency fuel delivery services, making it a reliable choice for companies seeking efficiency and mobility in fuel logistics.
Key Features
1. Reliable Isuzu Engineering
Built on Isuzu’s globally recognized 100P chassis, ensuring structural strength, fuel efficiency, and long-term durability even under demanding working environments.
2. Powerful and Efficient Engine
Equipped with the Isuzu 4KH1CN6LB 120HP diesel engine that delivers balanced performance with low emissions and excellent fuel economy.
3. Enhanced Safety Design
Features advanced ABS braking, front and rear axles with superior load-bearing capacity, and anti-surge tank design to reduce sloshing and improve driving stability.
4. Right-Hand Drive for Global Markets
Tailored for countries with left-hand traffic—such as Malaysia, Singapore, the UK, and Australia—ensuring maximum driving comfort and operational safety.
5. Operator Comfort and Control
The ergonomic cabin includes air conditioning, power steering, central locking, power windows, and a multifunction LCD dashboard for a smooth and safe driving experience.
6. Flexible Fueling Options
Supports optional systems like an electric fuel pump, automatic shut-off nozzle, hose reel, and precision fuel meter—ideal for various industries requiring efficient on-site refueling.
7. Wide Range of Applications
Perfect for mobile refueling, diesel transportation, construction and mining operations, agricultural machinery supply, and emergency energy delivery across different terrains and regions.
8. TWL Quality Assurance
Backed by TWL’s strict manufacturing standards, ensuring reliable performance, safe operation, and long service life for every delivered unit.
Product Specification
| Chassis Technical parameter | ||
| Driving mode | ISUZU 100P 4X2 | |
| Dimension | 6800*2400*3000mm | |
| Gross weight | 8000kg | |
| Curb weight | 3500kg | |
| Payload | 4500kg | |
| Wheelbase | 3360/3815mm | |
| Cabin | Steering wheel | Left hand drive or right hand drive |
| Configuration | With air conditioning | |
| Steering power | ||
| Central locking | ||
| Electric door and window | ||
| Engine | Engine brand | ISUZU 4KH1CN6LB |
| Horsepower | 120HP | |
| Displacement | 2300ml | |
| Emission standard | Diesel, EuroⅥ | |
| Type | 4 stroke, 4-cylinders in line, water cooling | |
| Transmission | ISUZU 5 forward gears and 1 reverse , Manual | |
| Tire | 7.00R16 | |
| Front axle loading | 2000-2500kg | |
| Rear axle loading | 4000-4800kg | |
| Upper structure parameter | ||
| Fuel tank capacity | 5m3/5,000liters | |
| Tank material | Carbon steel/ Stainless carbon/ Aluminum alloy | |
| Compartment No. | ONE | |
| Fuel dispenser | 2 sets, flow rate at 70L/min | |
| English operation panel | ||
| Showing unit price/ filling volume/ total price | ||
| Oil pump | 2 Nos of 2.5” Oil pumps, driven by TPO | |
| Independent pump in and pump out for each compartment | ||
| Filling hose | 1 inch and 15 meters | |
| 2 sets for diesel and petrol separately | ||
| Filling hose reel | 2 Nos | |
| Filling nozzle | 2 Nos | |
| Manhole cover | 2 sets with breath valves | |
| Bottom valve | 2 sets of APL aluminum pneumatic bottom valves | |
| Level gauge | Each tank top is equipped with an electronic level meter | |
| Operation compartment | Located at rear of truck with aluminum alloy door | |
| Control system | Power on/off | |
| Lighting | ||
| Fuel pump on/off | ||
| Fuel dispenser on/off | ||
| Main valve on/off | ||
| Fuel level digital display | ||
| Others | 2 sets of 4kg extinguishers | |
| 1 set of static belt | ||
| Painting | Color and design as customer’s requirement | |
| Special design | Tank body is covered by carbon steel van | |
ISUZU 100P 5m³ Diesel Refueling Truck Gallery
- +86 199 4767 5585
- [email protected]
- Industry Park, Suizhou City,Hubei Province, China
Company Profile
Aout TWL
HUBEI TWL SPECIAL VEHICLE CO., LTD (hereinafter referred to as TWL), one of important member of CLW Group, is located in Suizhou City, Hubei Province, the capital of China’s Special Vehicles. TWL Truck has a first-class management, design, R&D, manufacturing, and sales professional team, as well as “special, new, high and sophisticated” facilities and equipment, complete manufacturing technology, and strict testing methods to ensure the production of high-quality and high-value-added products for the market. At present, we has strategic partnership with a number of well-known Chinese truck brand, including Dongfeng, Sinotruk, FAW, Foton, Shacman, ISUZU, JAC, JMC, Kama, etc. TWL Truck always adheres to the corporate philosophy of “people-oriented, customer-oriented, honesty and win-win”, and adheres to the business tenet of “development by innovation, survival by quality; integrity by service, and market by brand”.
After-Sales Service
Warranty
– The buyers can get a minimum warranty period of 12 months or 25000KM-50000KM, whichever comes first from the arrival date of shipment.
– During this period, we will send replacement parts and components to buyers by DHL, UPS, FEDEX or by air and by sea free of charge, easy-wearing spare parts are excluded.
– After warranty time, buyers can get all of spare parts of their truck at factory cost.
– This warranty does not cover any possible damage due to improper operaton, accident or misuse or damage due to any unauthorized services.
Technical Support
– The buyers can forever enioy technical support anytime and anywhere, overseas technical training before operaton is available at buyers cost or our cost.
Daily Mainteance Suggestion
– We strongly sugest you to buy some amount of basic spare pats along with your truck, the cost will be approximately 500 USD-800 USD/unit, no shipping cost.
