Howo 20cbm Waste Recycling Hook Lift Garbage Truck
The Hook Lift Garbage Truck, also known as the Roll-off or Detachable Container Truck, is a versatile and efficient waste management vehicle. Equipped with a powerful hydraulic hook lift system, it enables quick loading and unloading of waste containers, significantly reducing manual labor and improving operational efficiency. Ideal for municipal waste collection, industrial waste transport, and commercial use.
Howo 20cbm Waste Recycling Hook Lift Garbage Truck
This hook lift garbage truck is designed to meet the demanding needs of modern waste management. With a robust structure, advanced hydraulic system, and multiple safety features, it ensures reliable performance in diverse working conditions. The truck supports a wide range of container sizes and is compatible with various international chassis brands.
Key Features:
· Hydraulic System: Custom-designed hydraulic cylinders, pumps, and valve systems from internationally recognized brands ensure smooth operation, high efficiency, and long service life.
· High-Strength Structure: The hook arm and lifting system are made of high-strength steel, treated with anti-corrosion and anti-deformation processes for enhanced durability.
· Safety Protection: Equipped with built-in unloading valves, explosion-proof locking devices, and overload protection to ensure safe operation under all working conditions.
· Interlock Protection: Prevents misuse through mechanical and hydraulic interlock systems, reducing maintenance costs and extending vehicle life.
· Versatile Compatibility: Suitable for various chassis brands and container types, offering flexibility for different waste collection scenarios.
Application:
· Municipal solid waste collection
· Industrial and construction waste transport
· Commercial and residential waste management
· Scrap metal and recyclable material handling
Product Specification
| HOWO 26Ton Hook lift garbage truck | ||
| Emission Standard | EUR 2 | |
| Model Name | YQF5252ZXXZZ6 | |
| Chassis model | ZZ3257N3847B1 | |
| Driving Type | 6×4 | |
| Dimensions | ||
| Wheelbase(mm) | 3800+1350 | |
| Overall Dimension(mm) | 8480x2550x3550(mm) | |
| Garbage container (mm) | 5500x2300x1500(L*W*H) | |
| Weights parameter | ||
| GVW(kg) | 25,000kgs | |
| Max. Payload (kg) | 35,000kgs | |
| Curb weight(kg) | 11,700kgs | |
| Front axle load(T) | VGD95 9Ton load capacity | |
| Rear axle load(T) | HC16 drum type 16Ton load capacity,ratio:5.73 | |
| Tread (Front/rear) (mm) | 2015/1830,1830 | |
| Front / rear overhang(mm) | 1430/1275 | |
| Max speed(km/h) | 89 | |
| Vehicle Frame,suspension | ||
| Frame | Double-deck frame(8+8/300) | |
| Suspension | Front and rear strengthen leaf spring 10/12 | |
| Tire | 12.00R20 18PR,total 10 tires + 1 spare tire | |
| Engine | ||
| Engine model | WP10.340E22 from WEICHAI engine | |
| Engine type | 4 stroke,direct injection,6 cylinder in-line,supercharge inter-cooling | |
| diesel engine,with engine exhausted brake | ||
| No. of cylinders | Straight-6 cylinders | |
| Displacement(L) | 9.726L | |
| Engine power(kw) | 250kw/340HP | |
| Max.torque/speed | 1250N.m/1400-1600rpm | |
| Drive Line parameter | ||
| Clutch description | Dry single plate,hydraulic control booster,mechanical operation with hydraulic assistance | |
| Transmission | HW19710+HW50 PTO | |
| 10 forwarder,2 reverse gear,Mechanical and Manual operation | ||
| Braking system | Service brake | Brake gap can be adjust automatically,dual air brake,without ABS |
| Assistant brake | WEVB(Engine exhaust brake) | |
| Park brake | Spring brake | |
| Steering wheel | BOSCHE steering wheel | |
| Cab description | ||
| 1. HW76 new cab,with cooling and heating air conditioner | ||
| 2. The cab can reversible forwardly | ||
| 3. One and half row,with sleeper bed | ||
Howo 20cbm Waste Recycling Hook Lift Garbage Truck
- +86 199 4767 5585
- [email protected]
- Industry Park, Suizhou City,Hubei Province, China
Company Profile
Aout TWL
HUBEI TWL SPECIAL VEHICLE CO., LTD (hereinafter referred to as TWL), one of important member of CLW Group, is located in Suizhou City, Hubei Province, the capital of China’s Special Vehicles. TWL Truck has a first-class management, design, R&D, manufacturing, and sales professional team, as well as “special, new, high and sophisticated” facilities and equipment, complete manufacturing technology, and strict testing methods to ensure the production of high-quality and high-value-added products for the market. At present, we has strategic partnership with a number of well-known Chinese truck brand, including Dongfeng, Sinotruk, FAW, Foton, Shacman, ISUZU, JAC, JMC, Kama, etc. TWL Truck always adheres to the corporate philosophy of “people-oriented, customer-oriented, honesty and win-win”, and adheres to the business tenet of “development by innovation, survival by quality; integrity by service, and market by brand”.
After-Sales Service
Warranty
– The buyers can get a minimum warranty period of 12 months or 25000KM-50000KM, whichever comes first from the arrival date of shipment.
– During this period, we will send replacement parts and components to buyers by DHL, UPS, FEDEX or by air and by sea free of charge, easy-wearing spare parts are excluded.
– After warranty time, buyers can get all of spare parts of their truck at factory cost.
– This warranty does not cover any possible damage due to improper operaton, accident or misuse or damage due to any unauthorized services.
Technical Support
– The buyers can forever enioy technical support anytime and anywhere, overseas technical training before operaton is available at buyers cost or our cost.
Daily Mainteance Suggestion
– We strongly sugest you to buy some amount of basic spare pats along with your truck, the cost will be approximately 500 USD-800 USD/unit, no shipping cost.
