Foton Auman 4×2 Refrigerated Truck
Engineered for demanding cold chain logistics, the Foton Auman 4×2 Refrigerated Truck combines a robust heavy-duty chassis with a high-insulation cargo body and professional-grade cooling unit. This 10-ton capacity vehicle delivers precise temperature control, structural integrity, and long-term reliability for transporting food, pharmaceuticals, and other temperature-sensitive goods.
Foton Auman 4×2 Refrigerated Truck
The Foton Auman Refrigerated Truck is purpose-built for industries requiring strict temperature control. Built on the proven Foton Auman heavy-duty chassis, the vehicle features reinforced construction and multiple drivetrain options including 4×2, 6×4, and 8×4 configurations. The high-insulation cargo body minimizes thermal transfer while maintaining uniform internal temperature, and the professional-grade cooling unit provides reliable operation across varied ambient conditions. With over 20 years of specialized vehicle manufacturing experience, this truck delivers consistent performance for cold chain logistics.
Key Features:
· Foton Auman Heavy-Duty Chassis: Built on a proven platform with exceptional structural strength. Available in 4×2, 6×4, and 8×4 drivetrain configurations to suit different operational requirements.
· High-Insulation Cargo Body: Advanced insulation materials minimize thermal transfer and maintain uniform temperature distribution for both chilled and frozen cargo.
· Professional-Grade Cooling Unit: Delivers precise temperature control suitable for food, pharmaceuticals, and other temperature-sensitive products. Reliable operation in varied ambient conditions.
· 10-Ton Payload Capacity: Substantial capacity for medium to large-scale cold chain operations. Cargo volume options from 10–15 m³ to 35+ m³, with customization available.
Flexible Chassis Options: Supports multiple brands including FAW, HOWO, ISUZU, DONGFENG, JAC, HINO, and more. Body lengths from 4.2m to 13.4m+ semi-trailers.
Application:
· Food Industry: Transporting fruits, vegetables, dairy, meat, seafood, and frozen foods under controlled temperatures.
· Pharmaceuticals: Reliable transportation of vaccines, medicines, and temperature-sensitive medical products.
· Beverages: Delivery of cooled soft drinks, beer, wine, and various beverages.
· Floral Industry: Maintaining freshness of flowers and plants during transportation.
· Retail and Supermarkets: Supplying perishable goods efficiently to stores.
Product Specification
| Max. driving speed(km/h) | 90 | |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 9850*2550*3700 |
| Wheel base (mm) | 5750 | |
| Wheel track (front/rear) (mm) | 1970/ 1830 | |
| Approach/Departure angle(°) | 19/10 | |
| Engine | Model | YC6A240-33 |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 240 | |
| Emission standard | Euro III | |
| Gearbox | FAST 8JS105TA, 8 Forwards gear & 1 reverse gear | |
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |
| Steering Gear | left hand drive,power steering, hydraulic steering with power assistance | |
| Fuel tank (L) | 200 | |
| Tire | 11R22.5 18PR tubeless tyre 6 pcs with 1 spare | |
| Brakes | Service brake: dual circuit compressed air brake | |
| Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels | ||
| Auxiliary brake: engine exhaust valve brake | ||
| Van size | 7000*2400*2400 | |
| Refrigerator | Thermo King/Carrier | |
| Temperature | 0 to -18 ºC | |
Foton Auman 4×2 Refrigerated Truck
- +86 199 4767 5585
- [email protected]
- Industry Park, Suizhou City,Hubei Province, China
Company Profile
Aout TWL
HUBEI TWL SPECIAL VEHICLE CO., LTD (hereinafter referred to as TWL), one of important member of CLW Group, is located in Suizhou City, Hubei Province, the capital of China’s Special Vehicles. TWL Truck has a first-class management, design, R&D, manufacturing, and sales professional team, as well as “special, new, high and sophisticated” facilities and equipment, complete manufacturing technology, and strict testing methods to ensure the production of high-quality and high-value-added products for the market. At present, we has strategic partnership with a number of well-known Chinese truck brand, including Dongfeng, Sinotruk, FAW, Foton, Shacman, ISUZU, JAC, JMC, Kama, etc. TWL Truck always adheres to the corporate philosophy of “people-oriented, customer-oriented, honesty and win-win”, and adheres to the business tenet of “development by innovation, survival by quality; integrity by service, and market by brand”.
After-Sales Service
Warranty
– The buyers can get a minimum warranty period of 12 months or 25000KM-50000KM, whichever comes first from the arrival date of shipment.
– During this period, we will send replacement parts and components to buyers by DHL, UPS, FEDEX or by air and by sea free of charge, easy-wearing spare parts are excluded.
– After warranty time, buyers can get all of spare parts of their truck at factory cost.
– This warranty does not cover any possible damage due to improper operaton, accident or misuse or damage due to any unauthorized services.
Technical Support
– The buyers can forever enioy technical support anytime and anywhere, overseas technical training before operaton is available at buyers cost or our cost.
Daily Mainteance Suggestion
– We strongly sugest you to buy some amount of basic spare pats along with your truck, the cost will be approximately 500 USD-800 USD/unit, no shipping cost.
