FAW JK6 6×4 Compactor Garbage Truck
The FAW JK6 6×4 Compactor Garbage Truck is a modern, high-efficiency waste collection vehicle designed and manufactured by Hubei TWL Special Vehicle Co., Ltd. Built on the robust FAW JK6 6×4 heavy-duty chassis, this truck integrates an advanced hydraulic compaction system to maximize waste load capacity and optimize collection routes. Engineered for durability, operational efficiency, and environmental hygiene, it is an ideal solution for municipal solid waste collection, urban sanitation, and industrial waste management.
FAW JK6 6×4 Compactor Garbage Truck
Key Advantages
1. Robust & Reliable Chassis
-
FAW JK6 6×4 chassis offers excellent load capacity, stability, and durability for heavy-duty waste collection.
-
Fuel-efficient engine meets modern emission standards while providing adequate power.
-
Comfortable cab with ergonomic design reduces operator fatigue during long shifts.
2. High-efficiency Compaction System
-
Advanced hydraulic compaction maximizes waste load per trip, reducing collection frequency.
-
High compaction ratio increases payload and optimizes fuel and operational costs.
-
Fast packing cycle time improves route efficiency and service coverage.
3. Durable & Hygienic Waste Body
-
High-strength steel construction with corrosion-resistant coating ensures long service life.
-
Sealed tailgate design prevents leakage and odor during transport.
-
Optional bin lift system reduces manual labor and improves operational safety.
4. Operator-friendly & Safe
-
Intuitive electro-hydraulic controls allow easy operation from cab or rear panel.
-
Safety features include overload protection, emergency stop, and safety interlocks.
-
Good visibility and accessibility for loading and unloading operations.
5. Versatile & Customizable
-
Configurable with various loading systems (lift arm, manual, rear/side loading).
-
Optional water spray system for dust suppression and cleaning.
-
Suitable for different waste types: municipal solid waste, commercial waste, industrial waste.
Applications
This FAW JK6 6×4 Compactor Garbage Truck is suitable for a wide range of waste collection and management scenarios:
-
Municipal Solid Waste Collection: Efficient collection of household waste in urban and suburban areas.
-
Commercial Waste Management: Service for shopping malls, markets, office complexes, and restaurants.
-
Industrial Waste Collection: Handling of general industrial waste from factories and warehouses.
-
Public Sanitation Services: Street cleaning support and public area waste collection.
-
Event & Festival Waste Management: Temporary waste collection for large public events.
-
Residential Community Services: Waste collection in housing estates, townships, and gated communities.
-
Airport & Port Sanitation: Waste management within transportation hubs.
Product Specification
| Category | Parameter | Specification |
| CHASSIS SYSTEM | Model | FAW JK6 6×4 Heavy-duty Truck Chassis |
| Engine | Diesel, approx. 240-280 HP, Euro V/VI compliant | |
| Transmission | Manual, 8-10 forward gears, 2 reverse gears | |
| Drive Type | 6×4 Rear-wheel drive | |
| Wheelbase | 4,500mm – 5,800mm (customizable) | |
| Max. Speed | 90-100 km/h | |
| Fuel Tank Capacity | 300-400 liters | |
| Tire Specification | 11.00R20 / 12.00R20 radial tires | |
| Brake System | Dual-circuit air brake, ABS optional | |
| Cab | Comfort cab, air-conditioned, seating for 2-3 | |
| COMPACTION SYSTEM | Compaction Mechanism | Hydraulic push-plate compactor |
| Compaction Ratio | Approx. 3:1 to 5:1 (depending on waste type) | |
| Packing Cycle Time | 20 – 30 seconds per cycle | |
| Control System | Electro-hydraulic control with in-cab and rear panel operation | |
| Safety Features | Overload protection, emergency stop, safety interlocks | |
| WASTE BODY SYSTEM | Body Material | High-strength steel (Q345) with anti-corrosion coating |
| Body Capacity | 12 – 20 cubic meters (compacted volume) | |
| Loading Method | Rear loading (lift arm or manual/bin lift system optional) | |
| Tailgate | Rear hydraulic tailgate with sealing rubber | |
| Hopper Volume | 1.5 – 2.5 m³ (loading hopper) | |
| Body Shape | Streamlined design for improved weight distribution | |
| HYDRAULIC SYSTEM | Hydraulic Pump | Gear pump or piston pump driven by PTO |
| Operating Pressure | 16 – 22 MPa | |
| Oil Tank Capacity | 150 – 250 liters | |
| Control Valves | Proportional control valves for smooth operation | |
| LOADING SYSTEM OPTIONS | Lift Arm | Optional hydraulic lift arm for standardized waste bins (660L/1100L) |
| Bin Capacity | Can service 2-4 bins per cycle (depending on configuration) | |
| Manual Loading | Rear opening for manual waste loading | |
| GENERAL VEHICLE | Overall Dimensions | Length: 8.5 – 10.5m, Width: 2.5m, Height: 3.5 – 3.8m |
| Gross Vehicle Weight (GVW) | 25 – 31 tons | |
| Curb Weight | Approx. 10 – 13 tons | |
| Payload Capacity | 12 – 18 tons (compacted waste) | |
| Min. Ground Clearance | ≥260mm | |
| Electrical System | 24V, dual batteries with isolator | |
| Lighting | LED headlights, work lights, warning beacons | |
| Water System | Optional rear spray system for dust and odor control | |
| Certification | Meets GB standards for waste collection vehicles |
