FAW J6P 50 Tons Rotator Wrecker Truck

Products Description

This is a multi-functional heavy-duty wrecker and recovery vehicle built on the reliable FAW J6P chassis. The “8×4” configuration provides a stable and powerful platform capable of carrying immense weights. It combines a heavy-lift crane with a powerful rotator/wrecker system, making it a versatile and indispensable tool for clearing major highway accidents, recovering construction equipment, and transporting heavy machinery.

Key Components and Their Functions

1. Chassis: FAW J6P 8×4

· Powerhouse: Typically equipped with a high-horsepower, high-torque diesel engine (XICHAI, 390HP, CA6DM series) to provide the necessary power for both mobility and intense hydraulic operations.
· Stability: The 8×4 wheelbase offers exceptional stability, which is critical when performing heavy lifts and recoveries. The chassis frame is reinforced to handle the stresses of crane operation and winching.
· Legal Payload: Designed to carry and recover vehicles and equipment up to its maximum rated capacity.

2. 50-Ton Crane Capacity Rotator Wrecker

· Function: This is the primary towing and recovery unit mounted at the rear of the truck.
· 50-Ton Capacity: Indicates it can lift and recover vehicles or loads weighing up to 50 metric tons (approximately 110,000 lbs). This covers a vast range of vehicles, from semi-trucks and buses to heavy construction machinery.
· Rotator Feature: This is the key difference from a standard wrecker. The entire boom and winch assembly can rotate 360 degrees continuously . This allows the operator to pull from any angle—from the side, front, or even from behind the truck without repositioning it. This is invaluable in complex accident scenarios where access is limited.
· Components:
Hydraulic Booms: Typically a telescopic main boom with an articulating jib (auxiliary boom) for greater reach and versatility.
Winches: Multiple powerful hydraulic winches (e.g., a main 50-ton winch and secondary 25-ton winches) with massive cable capacities.
Outriggers: Heavy-duty, hydraulically operated stabilizers that extend from the sides and rear to lift the truck off its suspension and create a stable platform for heavy lifting and winching.

3. 3-Stage Boom Crane

· Function: A separate, heavy-duty crane mounted behind the cab, used for lifting and placing heavy objects.
· 3-Stage Boom: The main boom consists of three telescoping sections. This allows for a compact retracted length and a very long extended reach, enabling the crane to lift loads over obstacles or place them at a distance.
· 360-Degree Rotation: The crane can swing a full circle, providing complete operational flexibility around the truck.
· Lifting Capacity: While the wrecker is rated for recovery (which involves dynamic forces), the crane has its own load chart, typically with a maximum capacity (e.g., 10-20 tons) that decreases as the boom is extended further.
· This crane is perfect for:
Loading and unloading heavy equipment onto flatbeds.
Lifting wrecked vehicles into position for recovery.
Placing counterweights or other recovery equipment.

4. Integrated Recovery System
The true power of this truck is the synergy between the crane and the rotator. The crane can be used to lift and stabilize a wreck, while the rotator simultaneously pulls it from another angle. This multi-point control is essential for complex, rolled-over, or precariously positioned recoveries.

Typical Workflow / Applications

1.Highway Accident Recovery: The primary role. The truck arrives, sets its outriggers, and uses the rotator’s 360-degree capability to pull a wrecked semi-truck or multiple cars from a difficult position.

2.Heavy Equipment Transport: The crane loads a disabled excavator or bulldozer onto a trailer, and the truck can then tow the trailer or act as a recovery vehicle for the convoy.

3.Industrial Recovery: Recovering machinery that has failed within a plant or factory site.
Utility Work: Assisting in placing heavy components like transformers.

4.Tunnel/Urban Roads Emergency Rescue: Accident Breakdown Trucks, Buses, Semitrailers Emergency Towing etc.

Advantages

· Unmatched Versatility: The combination of a rotator wrecker and a separate crane makes this a two-in-one solution, eliminating the need for multiple specialized vehicles.

· 360-Degree Capability: Maximum operational flexibility in confined or complex spaces. The operator is not limited by pull direction.

· Immense Power: Capable of handling the largest and most challenging recovery jobs on the road.

· Superior Stability: The 8×4 chassis and extensive outrigger system provide a safe and stable platform for critical heavy-lift operations.

· Efficiency: Reduces scene time for major accidents by providing multiple tools and approaches to a single problem.

Conclusion

The FAW J6P 8×4 with 360-Degree Rotator and 3-Stage Crane is not just a tow truck; it is a mobile heavy recovery command center . It represents the top tier of recovery technology, designed for government agencies, major towing companies, and heavy transport services that need to be prepared for any recovery scenario, anywhere.
