FAW J6F 6m³ Garbage Compactor Truck
The FAW J6F 6m³ Garbage Compactor Truck is a robust and efficient sanitation vehicle designed for urban and suburban waste management. Built on the reliable FAW J6F chassis and equipped with a high-strength compression system, this truck significantly reduces the volume of loose waste, allowing for more loads per trip and lower operational costs.
FAW J6F 6m³ Garbage Compactor Truck
This model combines the durability of the FAW J6F chassis with a state-of-the-art sealed garbage bin. The fully automated compression cycle ensures high loading capacity while preventing leakage and secondary pollution. Manufactured by Hubei TWL Special Vehicle Co., Ltd. , this vehicle meets international standards for quality and environmental protection.
Key Features:
Reliable Chassis: Powered by a FAW J6F high-horsepower engine, providing excellent fuel efficiency and smooth transmission.
Large Capacity: 6m³ corrosion-resistant steel bin, designed to handle various types of solid waste.
High Compression Ratio: Utilizes a push-pull blade system to compact waste, maximizing load capacity.
Sealed Structure: Full sealing prevents odor leakage and waste water spillage during transport.
User-Friendly Operation: Equipped with both manual and electric dual-operation control systems for convenience.
Durable Build: High-strength steel material ensures longevity and resistance to wear and tear.
Application:
Ideal for municipal sanitation departments, residential communities, commercial complexes, and industrial parks. Perfect for collecting domestic waste, garden waste, and light industrial solid waste.
Product Specification
| Technical Specifications | |
| Parameter | Details |
| Chassis Model | FAW J6F |
| Overall Dimensions (L×W×H) | 6,500 × 2,100 × 2,500 mm (approx.) |
| Garbage Bin Capacity | 6 m³ |
| Max Compression Ratio | 1:0.6 – 1:0.8 (depending on waste type) |
| Loading Cycle Time | ≤ 18 seconds |
| Unloading Cycle Time | ≤ 45 seconds |
| Max Payload | 3,000 – 4,000 kg (approx.) |
| GVWR (Gross Vehicle Weight Rating) | 7,300 kg (approx.) |
| Chassis & Drivetrain | |
| Parameter | Details |
| Engine Brand | FAW / Deutz (China IV/V/VI Emission Standard) |
| Engine Power | 130 HP – 160 HP |
| Transmission | Manual / Automatic (Optional) |
| Drive Type | 4×2 |
| Cab Capacity | 3 Persons |
| Steering | Power Steering |
| Brake System | Air Brake / Oil Brake (Optional) |
| Tire Size | 7.00R16 / 7.50R16 |
| Compactor Body & Hydraulic System | |
| Parameter | Details |
| Bin Material | High-Strength Wear-Resistant Steel (Q345 / T700) |
| Bin Thickness | Side: 3 mm / Bottom: 4 mm |
| Sealing Type | Fully Sealed with Rubber Seal Strip |
| Hydraulic System Pressure | 16 MPa |
| Hydraulic Oil Tank Capacity | 80 L – 100 L |
| Control System | Manual Valve + PLC Remote Control (Optional) |
| Loading & Unloading Mechanism | |
| Parameter | Details |
| Loading Method | Rear Loading (Compatible with standard dustbins) |
| Bin Lifting Capacity | 240 L / 660 L Standard Dustbins |
| Dumping Angle | ≥ 45° |
| Tailgate Opening Method | Hydraulic Up-Down / Side Swing (Optional) |
