FAW 7000L combined jetting truck
A powerful and versatile 2-in-1 vacuum sewer cleaning truck, engineered for high-efficiency sewage suction and high-pressure pipeline flushing. Combining a large 5,000L sewage tank with a 2,000L clean water tank, it ensures continuous, reliable operation for demanding municipal and industrial cleaning tasks.
FAW 7000L combined jetting truck
This integrated vacuum sewer cleaning truck is a premium solution for modern sanitation challenges. It seamlessly merges powerful vacuum suction capabilities with high-pressure water flushing in a single, robust unit. At its core, a dependable Cummins diesel engine powers both the renowned Jurop vacuum pump and the German-engineered PINFL high-pressure water pump. This synergy guarantees stable performance, straightforward operation, and superior working efficiency. Designed for durability and ease of maintenance, it is the go-to equipment for professionals seeking productivity and reliability in waste management and pipeline maintenance.
Key Features & Specifications
· Dual-Tank System: Features a large 5,000-liter (1,320 gal) sewage/sludge tank and a separate 2,000-liter (530 gal) clean water tank for independent or simultaneous operation.
· Premium Power & Components: Powered by a Cummins diesel engine, equipped with a high-performance Jurop vacuum pump and a German PINFL high-pressure pump for unmatched reliability and power.
· High-Efficiency Vacuum System: Designed to handle sludge, liquid waste, and semi-solid materials with powerful suction, facilitated by a large-diameter rear suction inlet with a flexible hose reel.
· Integrated Cleaning Function: The clean water tank enables high-pressure pipeline flushing and cleaning, allowing for continuous operation without external water sources.
· Advanced Protection System: Built-in cyclone oil-water separator protects the vacuum pump from damage, significantly extending its service life and reducing maintenance costs.
· Operator Safety & Convenience: Features a rear working platform with safety handrails and a clear vacuum pressure gauge for real-time system monitoring and safe, easy operation.
· Durable Construction: Reliable, corrosion-resistant pipeline and valve system ensures easy maintenance, long-term durability, and a prolonged service life.
Applications
This multifunctional truck is ideal for a wide range of sanitation and cleaning operations, including:
· Municipal Sanitation: Cleaning and maintenance of municipal sewer lines, storm drains, and catch basins.
· Septic Tank Services: Efficient desludging and cleaning of residential and commercial septic tanks.
· Industrial Waste Management: Handling industrial wastewater, sludge, and process waste from factories and plants.
· Pipeline Maintenance: High-pressure flushing and clearing of blocked pipelines in various settings.
· Emergency Cleanup: Rapid response for flood water removal, spill recovery, and other sanitation emergencies.
Product Specification
| FAW 7000L combined jetting truck | |||
| Cab | Chassis Brand | FAW Tiger VH | |
| Overall Dimension | 7250 x 2350 x 2580 mm | ||
| GVW | 112000 kg | ||
| Axle loads | 4000/7000 kg | ||
| Cab Capacity | flat-roof, single-row cabin, with A/C direction assistance | ||
| Engine | Fuel Type | Diesel, 4 cylinders in-line, 4-stroke, supercharged, intercooled, water-cooled | |
| Brand | Cummins | ||
| Model | ISF3.8s5154 | ||
| Power | 154 HP / 113kW | ||
| Rated speed | 2600rpm | ||
| Max torque | 491 N路m | ||
| Max torque speed | 1200-1900rpm | ||
| Displacement | 3.76L | ||
| Emission Standard | Euro 5 | ||
| Chassis | Drive Type | 4×2, left hand drive or right hand drive option | |
| Transmission | Wanliyang 6G55, 6-speed manual | ||
| Wheelbase | 4200mm | ||
| Number of axle | 2 | ||
| Tyre Specification | 235/75R17.5 | ||
| Tyre Number | 6 tyres and 1 spare tyre | ||
| Max Speed | 110km/h | ||
| Fuel tank | 100L | ||
| Paint | customization | ||
| Superstructure | Tank | Tank Capacity | 5000L sewage tank,2000L cleaning water tank |
| Tank Material | 5mm carbon steel with antiseptic treatment | ||
| Tank lifting angle | ≥45° | ||
| Vacuum Pump | Vacuum Pump | Jurop PN106D | |
| TYPE | Air cooled | ||
| MAX Vacuum | 92% | ||
| Max Pressure | 1.5 bar | ||
| Power Vacuum Max. | Vacuum pump 13.6kW | ||
| High cleaning water pump | Water pump brand | PINFL (German brand) | |
| Model | PF36 | ||
| Flow rate | 122 L/min | ||
| Rated pressure | 16 Mpa | ||
| Speed | 800 r/min | ||
| Power | 50kw | ||
| All standard accessories: manhole, tool kit, English manual….. | |||
| Hose Length | 80m high pressure hose | ||
| Suction hose | 8m | ||
| Discharge Method | Rear hydraulic opening and dumping | ||
| Suction Hose | Large-diameter suction hose with rear reel | ||
| Operation Type | Vacuum suction + water flushing | ||
| Optional | ** Tank material could be stainless steel. | ||
| ** Chinese or Spain vacuum pumps | |||
FAW 7000L combined jetting truck
- +86 199 4767 5585
- [email protected]
- Industry Park, Suizhou City,Hubei Province, China
Company Profile
Aout TWL
HUBEI TWL SPECIAL VEHICLE CO., LTD (hereinafter referred to as TWL), one of important member of CLW Group, is located in Suizhou City, Hubei Province, the capital of China’s Special Vehicles. TWL Truck has a first-class management, design, R&D, manufacturing, and sales professional team, as well as “special, new, high and sophisticated” facilities and equipment, complete manufacturing technology, and strict testing methods to ensure the production of high-quality and high-value-added products for the market. At present, we has strategic partnership with a number of well-known Chinese truck brand, including Dongfeng, Sinotruk, FAW, Foton, Shacman, ISUZU, JAC, JMC, Kama, etc. TWL Truck always adheres to the corporate philosophy of “people-oriented, customer-oriented, honesty and win-win”, and adheres to the business tenet of “development by innovation, survival by quality; integrity by service, and market by brand”.
After-Sales Service
Warranty
– The buyers can get a minimum warranty period of 12 months or 25000KM-50000KM, whichever comes first from the arrival date of shipment.
– During this period, we will send replacement parts and components to buyers by DHL, UPS, FEDEX or by air and by sea free of charge, easy-wearing spare parts are excluded.
– After warranty time, buyers can get all of spare parts of their truck at factory cost.
– This warranty does not cover any possible damage due to improper operaton, accident or misuse or damage due to any unauthorized services.
Technical Support
– The buyers can forever enioy technical support anytime and anywhere, overseas technical training before operaton is available at buyers cost or our cost.
Daily Mainteance Suggestion
– We strongly sugest you to buy some amount of basic spare pats along with your truck, the cost will be approximately 500 USD-800 USD/unit, no shipping cost.
