FAW 3 Tons Integrated Wrecker Tow Truck
The FAW 3 Tons Integrated Wrecker Tow Truck is a versatile rescue and recovery vehicle designed for handling accidents, breakdowns, and emergency road assistance. It is widely used for towing, lifting, traction, and clearing operations on expressways, city roads, and underground garages (ideal for “zombie car” towing).
Equipped with advanced technology and built with high-strength HG70 welded steel for critical components like the underlift and booms, this truck ensures durability and performance while reducing curb weight and fuel consumption.
The model supports multiple chassis options, including FAW, Sinotruk HOWO, Shacman, Dongfeng, Foton, JAC, JMC, and ISUZU, making it adaptable to various customer requirements.
FAW 3 Tons Integrated Wrecker Tow Truck Advantage
1. Performance & Practicality
American-applied technology: Proven, operator-centric design focusing on reliability and ease of use in daily rescue work.
Strong yet lightweight: HG70 high-strength welded steel in critical structures provides excellent durability with less mass.
Lower fuel consumption: Optimized curb weight and efficient hydraulics help reduce operating costs over the vehicle’s life.
High maneuverability: Compact integrated layout is ideal for underground garages and crowded city streets.
Rapid deployment: Intuitive controls and integrated structure speed up hookup, lift, and clear-scene times.
2. Flexibility & Customization
Wide chassis choices: FAW, HOWO, SHACMAN, DONGFENG, FOTON, JAC, JMC, ISUZU—match local service networks and driver familiarity.
OEM services: Tailor underlift attachments, tool storage, lighting, control interfaces, and branding to your operational playbook.
Series continuity: From mini garage units to heavy integrated and rotator boom models, fleets can standardize training and parts.
3. Reliability & Lifecycle Value
Materials that matter: HG70 steel offers high yield strength and fatigue resistance for sustained heavy use.
Consistent quality control: Welded-steel fabrication aligns strength, rigidity, and dimensional accuracy for predictable handling.
Global market validation: Growing adoption in America, Africa, Europe, and Russia reflects real-world reliability and cost-effectiveness.
Lower total cost of ownership: Reduced weight, mainstream chassis support, and simplified maintenance lower lifetime spend.
4. Safety & Operator Experience
Stable lifting/traction: Integrated design improves load control, helping reduce vehicle damage risk during recovery.
Visibility & signaling: Optional lightbars/work lights and conspicuity markings enhance night and low-light operations.
Ergonomic workflow: Logical control placement and organized tool storage support faster, safer task execution.
Product Specification
| General Technical Parameters | ||
| Overall Dimension | 5995x2150x2530(mm) | |
| Gross Vehicle Weight | 10695kg | |
| Curb Weight | 4695kg | |
| Chassis Specification | ||
| Chassis Brand | FAW Tiger VR | |
| Cabin | 3 persons, Left Hand Driving for Senegalmarket, with air conditioner | |
| Engine | Engine Brand | WEICHAl brand |
| Model | WP2.3NQ110E20, 4 Cylinders | |
| Power | 81KW/110HP | |
| Emission Standard | EURO III | |
| Displacement | 2290ml | |
| Fuel Type | Diesel | |
| Gearbox | WLYMG85B, Manual, 5 Forward &1 Reverse Gear | |
| Front and Rear Axle Load | 2T/5T | |
| Wheel Base | 3360(mm) | |
| Overhang( Front/Rear) | 1160/1475(mm) | |
| Wheel track (front/rear)(mm) | 1605/1520 | |
| Angle(Approach/departure) | 24/18(°) | |
| Brake System | Air Brake | |
| Steering Gear | Power Assistant | |
| Tire | 7.00R16, 6 pieces+1 spare tire | |
| Maximum Speed | 95(km/h) | |
| Fuel tank | 80L | |
| Superstructure | ||
| Maximum Towing weight(KGS) | 4495 | |
| Under Lifting System | Max. Under-lifting Weight(KGS) | 1500 |
| Max. Under-lifting Weight Full extension(KGS) | 1160 | |
| Lifting weight not extension(KGS) | 3000 | |
| Underlifting arm length(mm) | 1000-1520 | |
| Telescopic stroke(mm) | 600 | |
| Upward inclination angle | 11.6(°) | |
| Downward inclination angle | -4.5(°) | |
| Fold angle | -3-92(°) | |
| Maximum distance from the surface of the fully retracted cross arm to the ground(mm) | 630(mm) | |
| Hoist Lifting System | Max. Lifting Weight (kGs) | 4000 |
| Oil Cylinder Telescopic stroke(mm) | 1540 | |
| Max. Lifting Height (mm) | 2600 | |
| Lifting angle | 3.3-19.3(°) | |
| Winch | Quantity | 1pc |
| Rated traction force(KN) | 40 | |
| Steel Rope Diameter(mm) | Ф11 | |
| Steel Rope Length(m) | 25 | |
| Minimum linear speed(m/min) | 3.23 | |
FAW 3 Tons Integrated Wrecker Tow Truck Gallery
