Dongfeng KR 16m³ City Road Sweeper Washing Truck
Engineered for comprehensive municipal sanitation, the Dongfeng KR 16m³ City Road Sweeper & Washing Truck is a premium multi-functional cleaning vehicle integrating sweeping, high-pressure washing, garbage collection, and dust suppression into one intelligent system. Built on the reliable Dongfeng Kingrun 4x2 chassis with a Cummins 210HP main engine and a Cummins 170HP auxiliary engine, this vehicle features a 9m³ carbon steel water tank, 7m³ 304 stainless steel garbage tank, German Pumpe high-pressure pump, Weilong low-pressure pump (24m coverage), PLC intelligent control with 9 pre-set modes, and comprehensive safety protection systems.
Dongfeng KR 16m³ City Road Sweeper Washing Truck
The Dongfeng KR 16m³ Road Sweeper & Washing Truck is a purpose-built municipal sanitation vehicle designed for city sanitation departments, highway maintenance agencies, airport authorities, and industrial facility managers requiring superior cleaning performance. Built on the reliable Dongfeng Kingrun 4×2 chassis with left-hand drive, one-and-a-half row cab with sleeper, air conditioning, and power steering, this vehicle features a Dongfeng Cummins B210 33 main engine delivering 210HP (5.9L, 6-cylinder diesel, Euro III) paired with a FAST manual transmission (8 forward + 2 reverse). The dual-engine system includes a Cummins auxiliary engine producing 170HP (125 kW) dedicated to powering the sweeping and washing systems. The 16m³ total capacity is divided into a 9m³ carbon steel water tank for high-pressure cleaning and a 7m³ 304 stainless steel garbage tank (4mm thickness) for waste collection. The German Pumpe high-pressure pump provides powerful surface cleaning, while the Weilong 50/110 low-pressure pump delivers ultra-wide washing coverage up to 24 meters (8 lanes). The PLC intelligent control system features one-touch operation with 9 pre-set job modes, manual auxiliary engine throttle control for fuel optimization, and comprehensive safety protections including automatic clutch protection, intelligent reverse protection, tip-over prevention, voice alarms, fault self-diagnosis, anti-overflow/low-water alarms, and work/rearview cameras.
Key Features:
· Dongfeng Kingrun 4×2 Reliable Chassis: One-and-a-half row cab, LHD, 2-3 seats with sleeper, A/C, power steering. 6,000kg front axle, 10,000kg rear axle. 10.00R20 tires (7 pcs including spare). Full air brake system with parking spring brake and exhaust brake. 160L steel fuel tank.
· Cummins 210HP Main Engine + 170HP Auxiliary Engine: Dongfeng Cummins B210 33 main engine, 210HP, 5.9L, 6-cylinder diesel, Euro III. FAST 8F+2R manual transmission. Cummins auxiliary engine 170HP (125 kW) dedicated to sweeping/washing systems.
· 16m³ High-Capacity Tank System: 9m³ water tank (carbon steel) for high-pressure cleaning. 7m³ garbage tank (304 stainless steel, 4mm thickness) for waste collection. Corrosion-resistant stainless steel construction for long service life.
· Dual-Pump Washing System: German Pumpe high-pressure pump for powerful surface cleaning. Weilong 50/110 low-pressure pump with 24m coverage (8 lanes). Road barrier and wall cleaning capability. Small advertisement/graffiti removal.
· Intelligent Sweeping System: Adjustable ground pressure and variable brush speed. Sweeping width 2,800-3,200mm. Cleaning speed 3-15 km/h. Maximum sweeping efficiency up to 48,000 m²/h. Suction pipe diameter Φ200mm, vacuum negative pressure 380mm H₂O.
· PLC Intelligent Control with 9 Pre-Set Modes: One-touch operation for different cleaning scenarios. Manual auxiliary engine throttle control for fuel optimization. Programmable Logic Controller for reliable operation.
· Comprehensive Safety Systems: Automatic clutch protection (auxiliary engine ECU-controlled). Intelligent reverse protection (auto-stops operations during emergency reversing). Tip-over prevention for garbage tank. Safety interlocks for maintenance. Voice alarms and fault self-diagnosis. Anti-overflow/low-water alarms. Work cameras and rearview cameras.
· User-Centric Design: Front-mounted water tank and rear-mounted sewage tank. Semi-enclosed auxiliary engine compartment for easy maintenance. Taiwanese hydraulic valve blocks for smooth operation.
Application:
· City Street Cleaning: Daily sweeping and washing of downtown streets, pedestrian zones, and bus lanes.
· Highway Maintenance: Sweeping and washing of expressways, highways, and bridge decks.
· Airport Operations: Runway, apron, and taxiway cleaning; FOD (Foreign Object Debris) removal.
· Industrial Park Upkeep: Factory roadway cleaning, dust suppression, and spill cleanup.
· Large Public Area Maintenance: Parks, squares, stadiums, and convention center grounds.
· Road Barrier & Wall Cleaning: High-pressure washing of concrete and metal barriers.
· Graffiti Removal: Cleaning small advertisements and graffiti from walls, signs, and structures.
Product Specification
| Truck Chassis Parameters | |
| Component | Specification |
| Cabin | Dongfeng Kingrun one-and-a-half row cab, left-hand drive, |
| 2-3 seats with sleeper, air-conditioned, | |
| power steering. | |
| Engine | Dongfeng Cummins B210 33, 210HP, 5.9L, 6-cylinder diesel, Euro 3 emission standard. |
| Gearbox | FAST manual transmission, 8 forward + 2 reverse speed. |
| Axle Loading | Front axle: 6,000 kg; Rear axle: 10,000 kg. |
| Tires | 10.00R20 (7 pieces including spare). |
| Brake System | Full air brake system with parking spring brake and exhaust brake. |
| Fuel Tank | 160-liter steel fuel tank. |
| Upper Structure Parameters | |
| Parameter | Specification |
| Garbage Tank Volume | 7.0 cbm (Stainless Steel 304) |
| Water Tank Volume | 9.0 cbm (Carbon Steel) |
| Auxiliary Engine | Cummins, 125 kW / 170 HP |
| Sweeping Width | 2800-3200 mm |
| Cleaning Speed | 3-15 km/h |
| Max. Sweeping Efficiency | Up to 48,000 m²/h |
| Suction Pipe Diameter | Φ 200 mm |
| Vacuum Negative Pressure | 380mm H₂O |
