Dongfeng Duolika 4×2 6-Wheel 7m³ Hook Arm Lift Garbage Truck with Compactor Container

Key Features & Advantages

1. Hydraulic Hook Arm Lifting System
The truck is fitted with a robust hydraulic hook arm device that enables fast loading and unloading of compatible containers. One operator can complete container exchange operations easily, improving work efficiency and safety.

2. Detachable & Multi-Functional Container Design
Unlike fixed-body garbage trucks, this hook-lift model supports interchangeable containers. It can work with compactor bins, open dumpsters, flatbeds, water tanks, and other special-purpose containers, offering excellent flexibility for different tasks.

3. High-Efficiency Waste Compaction
The compactor container features a powerful hydraulic compression plate that compresses waste materials effectively, increasing the container’s loading capacity and reducing the number of trips required.

4. Independent Power System
The compactor bin is equipped with a dedicated power unit, allowing the compression process to operate independently from the truck engine. This design ensures stable performance and reduces wear on the vehicle chassis.

5. Durable Heavy-Duty Structure
Both the hook arm system and the compactor container are manufactured from high-strength steel, ensuring excellent durability, long service life, and reliable performance under continuous heavy-duty operation.

6. User-Friendly Loading Hopper
The compactor garbage bin is designed with a wide feeding opening and an optimized internal structure, making it suitable for loading loose domestic waste, commercial refuse, and recyclable materials.

Working Principle

1. Hook Loading & Unloading of the Container
The hydraulic cylinder extends to rotate the hook arm backward, allowing the container to be unloaded. When the cylinder retracts, the hook arm rotates forward to pull and load the container onto the chassis securely.

2. Container Locking Operation
After the container is loaded, the operator switches the mechanical locking handle to the locked position, ensuring the garbage bin is firmly fixed to the vehicle before operation.

3. Self-Unloading by Tilting
At the disposal site, the rear door of the container is opened, and the hydraulic system lifts the container to a maximum tilt angle together with the hook arm frame. Waste is discharged smoothly by gravity. After unloading, the hydraulic system resets the container and hook arm to their original position, completing the self-dumping process.
