LPG Tank Container

TWL LPG tank containers are purpose-built ISO tank units for transporting liquefied petroleum gases under pressure, such as propane, butane, or ammonia. Constructed with high-strength steel and housed in a durable ISO-standard frame, these containers are engineered for secure and stable operation in multimodal transport environments.
All containers comply with international safety standards and are available with certification from CCS, BV, LR, GL, or ASME. With a robust design, leak-proof sealing, and smart safety features, TWL tank containers ensure high-performance, global-capable LPG transport—whether by land, rail, or sea.

Key Features

1. Strong and Durable Construction
·Inner tank built from Q345R, SA516, or SA612N steel for high pressure resistance.
·ISO-standard box frame made of rectangular steel: light weight yet high strength.
·Available capacities from 24,600L to 25,000L.
2. Compliance & Certification
·Designed and manufactured per standards like:
·GB150-2011 (Pressure Vessel)
·ASME VIII Div.2
·IMDG Amdt.33-14
·TSG R005-2011 (Mobile Pressure Vessels)
·GB/T1836-1997 (Container Marking)
·Approved by CCS, LR, BV, GL, and others.
3. Safety Features
·Bottom rear discharge with excess flow valve & triple-closure system.
·Remote valve closure system with fusible link.
·Lockable valve cabinet for tamper protection.
·Equipped with level gauge, sunshield, and 500mm manlid.
4. Optional Configurations
·Available with or without zinc lining.
·Optional baffles for better liquid control during transport.
·Telemetry system for real-time monitoring (optional).
5.Multimodal Transport-Ready
·Suitable for sea freight, railway, and land transport.
·Compatible with global ISO container handling systems.
